Evaluation of potential left ventricular systolic dysfunction in patients with type 2 diabetes mellitus using ultrasonic myocardial work technology

doi:10.3877/cma.j.issn.1672-6448.2023.10.005

Abstract

Abstract:

Objective

To evaluate the abnormal changes of potential left ventricular myocardial systolic function and synchronization in patients with type 2 diabetes mellitus (T2DM) with and without obesity by applying myocardial work technique, and to investigate the clinical application of myocardial work parameters in assessing left ventricular systolic function in patients with T2DM.

Methods

A total of 70 patients with T2DM attending the endocrine outpatient clinic of Sichuan Provincial People's Hospital from December 2020 to August 2021 were selected and divided into two groups according to body mass index (BMI): 32 cases with T2DM not combined with obesity (BMI<25 kg/m²) and 38 cases with T2DM combined with obesity (BMI≥25 kg/m²). Forty-two age- and gender-matched healthy physical examiners were selected as a control group during the same period. All the three groups underwent conventional echocardiography to obtain left ventricular configuration and function parameters, and at the same time, speckle tracking and myocardial work techniques were used to obtain the global longitudinal strain (GLS), peak strain dispersion (PSD), global constructive work (GCW), global wasted work (GWW), global work index (GWI), and global work efficiency (GWE). The differences in the above parameters were compared among the three groups of parameters.

Results

The left ventricular ejection fraction (LVEF) decreased sequentially in the normal control group, the T2DM without obesity group, and the T2DM with obesity group, but the differences were not statistically significant (P>0.05). Compared with the normal control group, GLS, GCW, GWI, and GWE were decreased and GWW was increased in the other two groups. Compared with T2DM patients without obesity, GCW and GWE in T2DM patients with obesity were decreased significantly (P<0.05). Compared with the normal control group, PSD was significantly increased in T2DM patients with obesity (P<0.05).

Conclusion

Left ventricular myocardial systolic function may have already been impaired in T2DM patients with normal LVEF, and obesity may aggravate such impairment. Myocardial work parameters can more sensitively evaluate potential left ventricular systolic function impairment. Myocardial work technique could be used as an innovative method to evaluate left ventricular systolic function in T2DM patients with normal ejection fraction.

Key words: Myocardial work, Type 2 diabetes mellitus, Echocardiography, Obesity, Left ventricular function

Jinmei He, Lixue Yin, Jing Tan, Wenjun Zhang, Rui Wang, Mei Ren, Mingjiao Liao. Evaluation of potential left ventricular systolic dysfunction in patients with type 2 diabetes mellitus using ultrasonic myocardial work technology[J]. Chinese Journal of Medical Ultrasound (Electronic Edition), 2023, 20(10): 1029-1035.

/ / Recommend

Add to citation manager EndNote|Ris|BibTeX

URL: https://chaosheng.cma-cmc.com.cn/EN/10.3877/cma.j.issn.1672-6448.2023.10.005

https://chaosheng.cma-cmc.com.cn/EN/Y2023/V20/I10/1029

Figures/Tables 10

References 20

1	Petersmann A, Muller-Wieland D, Muller UA, et al. Definition, classification and diagnosis of diabetes mellitus [J]. Exp Clin Endocrinol Diabetes, 2019, 127(1): S1-S7.
2	Emerging Risk Factors C, Sarwar N, Gao P, et al. Diabetes mellitus, fasting blood glucose concentration, and risk of vascular disease: a collaborative meta-analysis of 102 prospective studies [J]. Lancet, 2010, 375(9733): 2215-2222.
3	Henning RJ. Type-2 diabetes mellitus and cardiovascular disease [J]. Future Cardiol, 2018, 14(6): 491-509.
4	Poirier P, Giles TD, Bray GA, et al. Obesity and cardiovascular disease: pathophysiology, evaluation, and effect of weight loss: an update of the 1997 American Heart Association Scientific Statement on Obesity and Heart Disease from the Obesity Committee of the Council on Nutrition, Physical Activity, and Metabolism [J]. Circulation, 2006, 113(6): 898-918.
5	Auclair A, Martin J, Bastien M, et al. Is there a role for visceral adiposity in inducing type 2 diabetes remission in severely obese patients following biliopancreatic diversion with duodenal switch surgery? [J]. Obes Surg, 2016, 26(8): 1717-1727.
6	Manganaro R, Marchetta S, Dulgheru R, et al. Echocardioimagedata reference ranges for normal non-invasive myocardial work indices: results from the EACVI NORRE study [J]. Eur Heart J Cardiovasc Imaging, 2019, 20(5): 582-590.
7	Haugaa KH, Grenne BL, Eek CH, et al. Strain echocardiography improves risk prediction of ventricular arrhythmias after myocardial infarction [J]. JACC Cardiovasc Imaging, 2013, 6(8): 841-850.
8	Authors/Task Force members, Elliott PM, Anastasakis A, et al. 2014 ESC Guidelines on diagnosis and management of hypertrophic cardiomyopathy: the task force for the diagnosis and management of hypertrophic cardiomyopathy of the European Society of Cardiology (ESC) [J]. Eur Heart J, 2014, 35(39): 2733-2779.
9	Burns AT, La Gerche A, D'Hooge J, et al. Left ventricular strain and strain rate: characterization of the effect of load in human subjects [J]. Eur J Echocardiogr, 2010, 11(3): 283-289.
10	Russell K, Eriksen M, Aaberge L, et al. A novel clinical method for quantification of regional left ventricular pressure-strain loop area: a non-invasive index of myocardial work [J]. Eur Heart J, 2012, 33(6): 724-733.
11	申凯凯, 朱好辉, 丁晓, 等. 无创左室压力应变曲线在评估血液透析患者左室心肌做功中的应用[J]. 中华超声影像学杂志, 2020, 29(6): 505-510.
12	李亚南, 崔存英, 刘园园, 等. 左室压力－应变环评估慢性心力衰竭患者左心室心肌做功的价值[J]. 中华超声影像学杂志, 2020, 34(1): 13-15.
13	陈绍琦, 庄泽敏, 陈庆子, 等. 超声智能检测技术测量正常中晚孕胎儿右心心肌做功指数[J/OL]. 中华医学超声杂志(电子版), 2021, 18(2): 188-192.
14	张娜, 吴青青, 孙丽娟, 等. 心肌做功指数在评价帆状胎盘孕妇胎儿心功能中的应用[J/CD]. 中华医学超声杂志(电子版), 2019, 16(7): 535-541.
15	Karnafel W. [Diabetic cardiomyopathy. Pathophysiology and clinical implications] [J]. Przegl Lek, 2000, 57 (4): 9-11.
16	徐河山. 2型糖尿病患者左室舒张功能的超声心动图评价[J]. 河南大学学报(医学版), 2009, 28(3): 226-227.
17	Alpert MA, Omran J, Bostick BP. Effects of obesity on cardiovascular hemodynamics, cardiac morphology, and ventricular function[J]. Curr Obes Rep, 2016, 5(4): 424-434.
18	Stanton T, Leano R, Marwick TH. Prediction of all-cause mortality from global longitudinal speckle strain: comparison with ejection fraction and wall motion scoring [J]. Circ Cardiovasc Imaging, 2009, 2(5): 356-364.
19	Hiemstra YL, van der Bijl P, El Mahdiui M, et al. Myocardial work in nonobstructive hypertrophic cardiomyopathy: implications for outcome [J]. J Am Soc Echocardiogr, 2020, 33(10): 1201-1208.
20	Huang D, Refaat M, Mohammedi K, et al. Macrovascular complications in patients with diabetes and prediabetes [J]. Biomed Res Int, 2017, 2017(7): 83-91.

临床资料	对照组（n=42）	T2DM不合并肥胖组（n=32）	T2DM合并肥胖组（n=38）	统计值	P值
年龄（岁）	41.83±11.44	47.19±9.07	46.47±11.05	F=2.88	0.061
男性[例（%）]	23（54.8）	25（78.1）	28（73.7）	χ^²=5.44	0.066
身高（cm）	164.50±7.14	168.06±7.01	165.45±16.02	F=5.35	0.069
体重（kg）	60.00±7.40	67.25±18.58	72.74±5.95^ab	F=41.74	<0.001
收缩压（mmHg）	115.62±6.28	120.13±6.60^a	120.95±9.00^a	F=14.21	<0.001
舒张压（mmHg）	73.50±7.17	75.97±6.28	76.42±6.35	F=2.23	0.113
心率（次/分）	72.31±9.14	78.44±10.48^a	81.79±12.36^a	F=15.58	<0.001
BMI（kg/m²）	22.13±1.86	22.63±1.69	25.82±0.80^ab	F=75.35	<0.001
FPG（mmol/L）	4.50±0.28	9.67±1.60^a	9.61±1.58^a	F=78.16	<0.001

临床资料	对照组（n=42）	T2DM不合并肥胖组（n=32）	T2DM合并肥胖组（n=38）	统计值	P值
年龄（岁）	41.83±11.44	47.19±9.07	46.47±11.05	F=2.88	0.061
男性[例（%）]	23（54.8）	25（78.1）	28（73.7）	χ^²=5.44	0.066
身高（cm）	164.50±7.14	168.06±7.01	165.45±16.02	F=5.35	0.069
体重（kg）	60.00±7.40	67.25±18.58	72.74±5.95^ab	F=41.74	<0.001
收缩压（mmHg）	115.62±6.28	120.13±6.60^a	120.95±9.00^a	F=14.21	<0.001
舒张压（mmHg）	73.50±7.17	75.97±6.28	76.42±6.35	F=2.23	0.113
心率（次/分）	72.31±9.14	78.44±10.48^a	81.79±12.36^a	F=15.58	<0.001
BMI（kg/m²）	22.13±1.86	22.63±1.69	25.82±0.80^ab	F=75.35	<0.001
FPG（mmol/L）	4.50±0.28	9.67±1.60^a	9.61±1.58^a	F=78.16	<0.001

超声参数	对照组（n=42）	T2DM不合并肥胖组（n=32）	T2DM合并肥胖组（n=38）	F 值	P值
LVPWT（mm）	7.74±1.08	8.72±1.17^a	8.71±1.43^a	16.44	<0.001
LVEDD（mm）	43.33±4.78	42.91±3.51	43.79±4.30	0.40	0.820
LVESD（mm）	24.24±3.65	24.28±3.02	25.16±4.36	0.97	0.617
IVST（mm）	6.74±1.08	7.44±1.22^a	7.53±0.98^a	12.14	0.002
LAD（mm）	26.81±3.18	25.53±3.22	27.00±3.81	3.76	0.152
LVEDV（ml）	74.12±17.01	73.09±15.40	73.11±21.95	0.57	0.752
LVESV（ml）	28.14±10.49	28.16±9.09	30.21±12.33	0.64	0.727

超声参数	对照组（n=42）	T2DM不合并肥胖组（n=32）	T2DM合并肥胖组（n=38）	F 值	P值
LVPWT（mm）	7.74±1.08	8.72±1.17^a	8.71±1.43^a	16.44	<0.001
LVEDD（mm）	43.33±4.78	42.91±3.51	43.79±4.30	0.40	0.820
LVESD（mm）	24.24±3.65	24.28±3.02	25.16±4.36	0.97	0.617
IVST（mm）	6.74±1.08	7.44±1.22^a	7.53±0.98^a	12.14	0.002
LAD（mm）	26.81±3.18	25.53±3.22	27.00±3.81	3.76	0.152
LVEDV（ml）	74.12±17.01	73.09±15.40	73.11±21.95	0.57	0.752
LVESV（ml）	28.14±10.49	28.16±9.09	30.21±12.33	0.64	0.727

超声参数	对照组（n=42）	T2DM不合并肥胖组（n=32）	T2DM合并肥胖组（n=38）	F 值	P值
E（cm/s）	87.93±18.32	75.38±15.71^a	75.68±13.15^a	7.90	0.001
A（cm/s）	71.40±15.27	73.56±18.08	84.37±17.30^ab	6.59	0.002
E/A	1.31±0.45	1.07±0.36^a	0.95±0.25^a	20.06	<0.001
e（cm/s）	14.02±2.51	11.28±2.98^a	10.53±2.44^a	19.60	<0.001
a（cm/s）	10.95±1.75	10.66±1.36	11.37±1.78	2.10	0.350
e/a	1.31±0.38	1.13±0.40	0.96±0.31^a	19.65	<0.001
E/e	6.39±1.23	6.91±1.72	7.46±1.78^a	7.99	0.018
